iRack

  • ISTS A1

  • ISTS B1

  • ISTS B2

  • ISTS B4

With a MTBF of 800,000 hours, Static Power’s 19″ iRACK are dedicated to applications requiring a high level of reliability.

All iSTS B models can be supplied with an integrated maintenance bypass with hot socket field replaceable power module facilitating maintenance and reducing Time To Repair at its minimum.

All our 19″rack iRACK are adaptable to particular applications or requirements.

Features

✔️ True solid state, Break-Before-Make transfer

✔️ Transfer time: <1ms to ¼ cycle

✔️ MTBF > 800,000h

✔️ Hot socket replaceable power module

✔️ Maintenance bypass

✔️ Incoming source isolators

✔️ HTTP, SNMP, MODBUS TCP, eMail and NTP

ISTS A1.png
iSTS B2.png
iSTS B4.png
iSTS B1.png

Key Features

• Up to 32A, Single phase

• Maintenance bypass with hot socket field replaceable power module

• Built-in transient voltage protection

• UPS Eco-Mode compatible

• RCD site compatible

• Safe asynchronous source transfers

• Very high MTBF (>800,000 hours)

• Back feed protection contactors

• Manual or automatic transfer selection

• Integrated web server

• High-level interface – MODBUS, SNMP

• Email alerts

• Clock synchronisation with NTP

• Remote operation

• Preferred source selection

• Visual and sound alarms

• LED mimic with graphic OLED interface and load indicator

• Additional voltage free general alarm contact

• Up to 32A, Single phase

• Built-in transient voltage protection

• UPS Eco-Mode compatible

• RCD site compatibility

• Safe asynchronous source transfers

• Very high MTBF (>800,000 hours)

• Back feed protection contactors

• Manual and automatic transfers selection

• Various input/output configuration

• Preferred source selection

• Visual and sound alarms

• Bi-colour LED mimic and load indicator

• Voltage free general alarm contact

• Ethernet module for LAN/TCP, Modbus & SNMP

Up to 125A, Single phase and 63A 3-Phases

• Built-in transient voltage protection

• UPS Eco-Mode compatible

• Safe asynchronous source transfers

• Very high MTBF (>800,000 hours)

• LED mimic decal with graphic OLED interface

• One touch transfers

• Visual and sound alarm

• Integrated web server

• Remote operation

• High-level interface – MODBUS, SNMP

• Email alerts

• Clock synchronisation with NTP

• Integrated maintenance bypass with hot socket field replaceable power module

• Incoming source isolator switches

• Redundant fan cooling

• Fixed wiring to terminals

• 5 x voltage free contacts & remote inputs

Up to 250A, Single phase and 160A, 3-Phases

• Rack-mount 4RU Design

• Built-in transient voltage protection

• UPS Eco-Mode compatible

• Safe asynchronous source transfers

• Very high MTBF (>800,000 hours)

• LED mimic decal with graphic OLED interface

• One touch transfers

• Visual and sound alarm

• Integrated web server

• Remote operation

• High-level interface – MODBUS, SNMP

• Email alerts

• Clock synchronisation with NTP

• Incoming source isolator switches

• Integrated maintenance bypass with hot socket field replaceable power module

• Fixed wiring to input & output terminals

• 5 x Voltage free contacts & remote inputs
